Proline Low-temperature Thermostats
YACE0072 / 21.08.07 Accessories 119
10 Accessories
Description Application
LAUDA
Order No.:
LAUDA Wintherm Plus
PC Program.
Control of the thermostat, online display of all
values as a graph with free choice of time
frame. Incl. RS 232 cable (2m).
LDSM2002
RS232/ 485 Interface modules. Digital Communication, operation of the
LAUDA PC software Wintherm Plus Ì 8.3.
LRZ 913
RS 232 Cable (2m). Thermostat-PC Sub-D (9 pin. 9 pin). EKS 037
RS 232 Cable (5m). Thermostat-PC Sub-D (9 pin. 9 pin). EKS 057
Analogue module. Current and voltage interface Ì 8.4. LRZ 912
Relays module with 3 input and 3 output
channels.
Import and export of thermostat signals
Ì 8.5.1.
LRZ 915
Relays module with 1 input and 1 output
channel.
NAMUR NE28 functionality Ì 8.5.2.
LRZ 914
T-piece adapter cable for the LAUDA
internal bus (LiBus) {.
For the connection of further LiBus
components (with heating thermostats two
LiBus { connections are not occupied and
one with cooling thermostats).
EKS 073
Extension for LiBus { 5m. EKS 068
Extension for LiBus { 25m.
For LiBus { components, but especially for
remote operation with the command console.
EKS 069
Automatic refill device with LiBus {
control.
Evaporating heat carrier liquid is automatically
topped up.
LCZ 9661
Shut-off unit with LiBus { control. Prevents the return of cooling liquid into the
bath from external containers located above
the bath.
LCZ 9673
Controlled high temperature cooler,
control via LiBus {.
For the rapid cooling of high bath
temperatures, using water cooling.
LCZ 9663
Level controller without reverse-flow
protection, mechanical function.
Keeps the liquid level in an open external
bath at a constant level.
LCZ 0660
Raising platform 300x200 mm
for P 18, RP 1840/1845.
For lowering and lifting out objects
for P 18, RP 1840/1845.
LCZ 0664
Raising platform 300x350 mm
for P 26, RP 3530.
For lowering and lifting out objects
for P 26, RP 3530 (depth 250 mm).
LCZ 0665
Application frame
for 56 tubes, diam. 10-13 mm 80 mm
ID|.
2 frames fit in each of P 18, RP 1840 and
RP 1845; 4 frames fit in P 26. UG 070
Application frame
for 33 tubes, diam. 14-18 mm 80 mm
ID|.
2 frames fit in each of P 18, RP 1840 and
RP 1845; 4 frames fit in P 26. UG 071
Application frame
for 33 tubes, diam. 14-18 mm 110 mm
ID|.
2 frames fit in each of P 18, RP 1840 and
RP 1845; 4 frames fit in P 26. UG 072
