LAUDA Ultra-Thermostats
UB 20(-D), UB 25, UB 50, UB 30, UB 40
UB 20 F, UB 20 J, UB 30 J, UB 40 J, UB 65 J
UB 20 JL, UB 30 JL, UB 40 JL
YATE0013 / 10.04.02
- 65 -
Cover plate UB 25/4
4 openings 100 mm dia., 4 sets water bath rings,
4 rising platforms, 4 stand rods Cat. No. LTZ 014
Cover plate UB 50/4
4 openings 195 mm dia., 4 sets water bath rings,
4 rising platforms, 4 stand rods Cat. No. LTZ 015
Cover plate UB 50/8
8 openings 100 mm dia., 8 sets water bath rings,
8 rising platforms, 8 stand rods Cat. No. LTZ 016
Rising platform or cover plate with rising platform for UB 30 or UB 40 on request.
LAUDA Through-Flow Chillers
for cooling thermostats, in particular DLK 10 Cat. No. LFD 105
at operating temperatures below DLK 25 Cat. No. LFD 106
the working temperature range DLK 45 Cat. No. LFD 107
LAUDA Pt 100 platinum resistance thermometers
to DIN IEC 751 Class A for external control
and other temperature measurement
Pt 100-42
all-glass version with NS 14/23 ground taper DIN 12242
Temp. range -100...300°C
50% response time 0.8 sec
Overall length approx. 115 mm
4-wire circuit Cat. No. ETP 049
Fig. 1
Pt 100-44
all-glass version with NS 14/23 ground taper DIN 12242
Temp. range -100...300°C
50% response time 0.8 sec
Overall length approx. 320 mm Cat. No. ETP 007
Fig. 2
Pt 100-66
as Pt 100-44
Overall length approx. 430 mm Cat. No. ETP 008
Fig. 2
Pt 100-90
stainless steel protection tube 4 mm dia.
Temp. range -100...300°C
50% response time 1.5 sec
Overall length approx. 120 mm
4-wire circuit Cat. No. ETP 050
Fig. 3
