LAUDA Ultra-Thermostats
UB 20(-D), UB 25, UB 50, UB 30, UB 40
UB 20 F, UB 20 J, UB 30 J, UB 40 J, UB 65 J
UB 20 JL, UB 30 JL, UB 40 JL
YATE0013 /10.04.02
- 66 -
Pt 100-70
stainless steel protection tube 4 mm dia.
Temp. range -200...300°C
50% response time 1.5 sec
Overall length approx. 290 mm
4-wire circuit Cat. No. ETP 009
Fig. 3
Pt 100-92
stainless steel protection tube 4 mm dia.
with attached Silicone cable 2 m long and plug
Temp. range -100...200°C
50% response time 3 sec
Overall length approx. 250 mm
4-wire circuit Cat. No. ETP 051
Fig. 4
Connecting cable
with 4-pin plug for external control on
all C-and K-units and for
digital thermometer for Pt 100-44 and
Pt 100-66 1.5 m Cat. No. UK 048
length as specified Cat. No. UK 213
for Pt 100-42, Pt 100-70, Pt 100-90 1.5 m Cat. No. UK 047
length as specified Cat. No. UK 212
Screw clamp fitting
stainless steel, with Teflon pressure ring
for Pt 100 resistance thermometer 4 mm dia. Cat. No. HX 078
Fig 5
