Lauda VS 8 O - 13 Connection to the Mains Supply; Electrical Fuses

20 / 34 Varioshake Shaking Apparatus 09/2020
13 Connection to the mains supply
LAUDA-GFL Varioshake Shaking Apparatus are supplied with a pre-assembled, cast-on shock-proof plug (CEE 7/7).
Make sure to connect to a protective conductor terminal.
Colour coding of the mains cable Mains supply
ge/gr
–
yellow
/gr
ee
n
PE (Protective earth)
bl
–
blue
N
sw
–
black
L1
Electrical fuses 13.1
Model
Power
Power consumption at mains voltage
*
Mains fuse
(F4, F5)
VS 8 O
VS 8 B
VS 8 OE
VS 8 B
E
0.065 kW 0.3 A at 230 V 10 A
(max. 16 A)
Model
Power
Power consumption at mains voltage
*
Mains fuse
(F4, F5)
VS 15 O
VS 15 B
0.065 kW 0.3 A at 230 V 10 A
(max. 16 A)
Model
Power
Power consumption at mains voltage
*
Mains
fuse
(F4, F5)
VS 15 T
VS 15 R
VS 30 O
0.090 kW 0.4 A at 230 V 10 A
(max. 16 A)
* see nameplate
