CONTINUOUS FAST WEIGHT TRANSMISSION PROTOCOL
This protocol allows the continuous transmission of the weight at high update frequencies. Up to 300
strings per second are transmitted with a minimum transmission rate of 38400 baud.
Following communication modes availables (see section SERIAL COMMUNICATION SETTINGS):
: communication compatible with TX RS485 instruments
: communication compatible with TD RS485 instruments
If is set, the following string is transmitted to PC/PLC:
xxxxxxCRLF
where: xxxxxx ...... 6 characters of gross weight (48
57 ASCII)
CR ................ 1 character return to the start (13 ASCII)
LF ................ 1 character on new line (10 ASCII)
In case of negative weight, the first character from the left of the weight characters takes on the
value “-” (minus sign - ASCII 45).
In case of error or alarm, the 6 characters of the weight are substituted by the messages
found in the table of the ALARMS section.
If is set, the following string is transmitted to PC/PLC:
&TzzzzzzPzzzzzz\ckckCR
where: & ................... 1 initial string character (38 ASCII)
T ................... 1 character of gross weight identification
P ................... 1 character of gross weight identification
zzzzzz ...... 6 characters of gross weight (48
57 ASCII)
\ ................... 1 character of separation (92 ASCII)
ckck ........... 2 ASCII control characters or calculated considering the characters included
between “&” and “\” excluded. The control value is obtained executing the
XOR operation (exclusive OR) for the 8 bit ASCII codes of the characters
considered. Therefore, a character expressed in hexadecimal is obtained with
2 numbers that may assume values from “0” to “9” and from “A” to “F”.
“ckck” is the ASCII code of the two hexadecimal digits
CR ................ 1 character of end string (13 ASCII)
In case of negative weight, the first character from the left of the weight characters takes on the
value “-” (minus sign - ASCII 45).
In case of error or alarm, the 6 characters of the gross weight are substituted by the
messages found in the table of the ALARMS section.
