MAIN SPECIFICATIONS OF THE INSTRUMENT
Indicator with 6-wire load cell input installable on table, wall or column. Dimensions:
120x200x280 mm. 6-digit semi-alphanumeric red LED display (20 mm height), 8 signaling LED.
5-key mechanical keyboard. D-SUB connectors. IP40 protection rating.
Real-time clock/calendar with buffer battery.
A RS232 serial port for connection to: PC/PLC up to 32 instruments (max 99 with line repeaters) by
ASCII Laumas or ModBus R.T.U. protocols, remote display, printer.
24 VDC/1 A stabilized power supply included.
Designed to operate with 8 NiMH rechargeable batteries, 1.2 V, AA type (not included).
BUFFER BATTERY
The instrument is equipped with an internal battery that allows to keep active the internal clock even
in the event of power failure.
At the first start and after long periods of inactivity, leave the instrument on for at least 12
hours to fully charge the battery.
