LAUNCH Tyre Changer (TWC-502RMB)
2
Main Structure
Fig.01-1
The main structure is shown in Fig. 01-1.
A
Return spring
B
Swing arm
C
Hexagonal column
D
Mount/demount head
E
Clamping jaw
F
Turntable
G
Tilting column
control pedal
H
Clamping cylinder
control pedal
I
Bead breaker
control pedal
J
Turntable control pedal
K
Hexagonal column
locking handle
L Tilting column
N
Clamping cylinder
assembly
O
Hanger
P
Bead breaker
handle
Q
Bead breaker arm
R
Ajusting pin
S
Bead breaker shoe
T
Tyre lever
U
Inflation pedal
V
Air Pressure Regulator, Gauge and Lubricator Assembly
W
Supplementary arm
assembly
