LAUNCH X-431 PRO3 V4.0 User Manual
11
4
Diagnostic cable
To connect the VCI module to
vehicle’s DLC.
1
5
Cigarette lighter
cable
To supply power to the VCI module
through connection to cigarette
lighter receptacle.
(optional)
6
Battery clamps
cable
To supply power to the VCI module
through connection to vehicle’s
battery.
(optional)
7
Power adaptor
To charge the tablet through
connection to AC outlet.
1
8
Power adaptor
(For VCI module)
To supply power to the VCI module
through connection to AC outlet.
1
9
USB cable with
B-shaped terminal
To connect the VCI module and
diagnostic tool to perform vehicle
diagnosis.
1
10
Non-16pin
adaptor cable kit
For different vehicle diagnostic
socket, it may be necessary to use
one of the adaptor cables included
within the kit.
For detailed non-16pin adaptor
cables, please check the package
box.
(optional)
1.5 Package List (Only for Gasoline & Diesel Configuration)
Common accessories are same, but for different destinations, the accessories
(such as diagnostic software, testing connectors) may vary. Please consult from
the local agency or check the package list supplied with this tool together.
No. Item Descriptions Qt.
1 Display tablet
The central processor and monitor
for analyzing vehicle data and
1
