LAUNCH
3001
User’s Manual
1
1. Introduction
The CReader 3001 is specially developed by LAUNCH, which support all 10
modes of OBD II test for a complete diagnosis. Featuring the 1.77” color LCD, it
enables users to read/clear DTCs, record and save data. The CReader 3001 is
also very easy to use. With built-in help menus and code definitions, diagnosing
and repairing that dreaded Check Engine Light is now easier than ever!
Moreover, CReader 3001 also features the following bi-directional “special tests”:
EVAP, O
2
Sensor, I/M Readiness, MIL Status, VIN Info, and On-board monitors
testing.
It can be connected to PC through the USB cable for upgrade to keep updated
with the latest software version.
Note: CReader 3001 may automatically reset while being disturbed by strong static
electricity. THIS IS A NORMAL REACTION.
This tool is specially designed to work with all OBD 2 compliant vehicles, including
Controller Area Network (CAN). It is required by EPA that all 1996 and newer
vehicles (cars and light trucks) sold in the United States must be OBD 2 compliant
and this includes all American, Asian and European vehicles.
A small number of 1994 and 1995 model year gasoline vehicles are OBD 2
compliant. To verify if a 1994 or 1995 vehicle is OBD 2 compliant, check the
following:
1.
Vehicle Emissions Control Information (VECI) Label
. It is located under the
hood or by the radiator of most vehicles. If the vehicle is OBD 2 compliant, the
label will designate “OBD 1I Certified”.
2. Government regulations mandate that all OBD 2 compliant vehicles
must
have
a “common” 16-pin
Data Link Connector (DLC)
.
