LAUNCH
529 OBD II Scanner User’s Manual
3. Components & Controls
3.1 Controls
No. Name Notes
1
Cable with OBD II
CONNECTOR
Connects the scanner to the vehicle’s
Data Link Connector (DLC).
2 LCD SCREEN
Shows menu and submenus and test
results.
