2.1 CRP229 Display Tablet
Fig. 2-3 CRP229 Display Tablet (front & rear view)
2 Knowledge of CRP229
There are two main components to the CRP229 system:
CRP229 Display Tablet -- the central processor and monitor for the •
system (For details, please refer to Chapter 2.1.)
Fig. 2-1
Diagnostic Main Cable -- the cable used to connect CRP229 to •
diagnostic connector for accessing vehicle data
Fig. 2-2
