Put extension rod on the rim distance pointer as shown in the above figures.
Use the same method mentioned above, take reading from the distance gauge.
Release the rim distance pointer to home position, enter the wheel offset a value (a=the
above mention reading +6)
The procedure to enter rim diameter d and rim width b are described in the section 5.2.and
5.3
9.5 Rim data entry for ALU-s mode. Mode ALU-s for rims with special profile. Press [ALU] key
to toggle balancing modes , the corresponding LED of ALU-s light up on the display window on
the operation panel.
dI dE
I E
aI
aE
Refer to the above figure, take measurement of each distances, enter wheel data according
to the following procedure.
Press key [a↑] [a↓] to change aI value.
Press key [b↑] [b↓] to change aE value.
Press key[ d↑] [d↓] to change dI value.
Press and hold key [ALU], then press key [d↑] [d↓] to change dE value.
12
