5.UNPACKING
When unpacking, check to make sure all the parts shown on the Packing Lists are in-
cluded. If any parts are missing or broken, please call the distributor as soon as possible.
6.INSTALLATION AND ASSEMBLY INSTRUCTIONS
NOTE: For additional references to the parts listed below, refer to the Assembly
Diagrams).
CAUTION - DO NOT REMOVE OIL/GREASE COMPOUND FROM THE SPIN
SHAFT AND FROM TIME TO TIME SWAB A GOOD QUALITY GRAPHITE GREASE
TO AVOID RUSTING.
6.1To Determine The Proper Location For The Wheel Balancer:
1.WARNING: Make sure this machine is used on a dry, oil/grease free, flat, level CON-
CRETE surface capable of supporting the weight of the Wheel Balancer, the wheel be-
ing balanced, and any additional tools and equipment.
2.The Wheel Balancer is designed for indoors use only. Do not install or use the
Wheel Balancer outdoors, or in damp or wet locations.
3.Make sure to check the desired location for possible obstructions such as a low ceiling,
overhead lines, adequate working area, access ways, exits, etcetera.
The Wheel Balancer should be located in an area free of flammable materials and liq-
uids.
6.2 To Mount The Wheel Balancer On A Floor Surface:
1.With assistance, and with the use of a lifting device, stand the Wheel Balancer in its up-
right position in the desired work location. Use the three, 1/2” machine mounting holes
located at the base of the Body as a template to mark the points where three floor an-
chor holes will be drilled in the floor surface. Then, temporarily remove the Wheel Bal-
ancer. (See Figure B, next page.)
2.Where previously marked on the concrete floor surface, drill three 1/2” diameter, mini-
mum 4” deep, anchor holes. NOTE: Be sure to blow out the cement dust from the
drilled holes.
4.2.14 WARNING: This product contains or produces a chemical known to the State
of California to cause cancer and birth defects (or other reproductive harm).
(California Health & Safety Code 25249.5 et seq.)
WARNING: People with pacemakers should consult their physician(s) before using this
product. Operation of electrical equipment in close proximity to a heart pacemaker
could cause interference or failure of the pacemaker.
6
Single phase motor
Capacity of circuit
breaker
110V to 120V
25A
220V to 240V
16A
3 Phase motor
Capacity of circuit
breaker
220V to 230V 16A
380V to 415V 10A
To Next Page
