Launch TLT235、TLT240 Economical Two-post User’s Manual
33
No. Code Name
1 201021649 TLT235SC(U) Power side column
2
201021648
TLT235SC(U) Offside column
4
103202858 Protective cover inside the column
6
103201070 Bottom cover of column
7 103010498 Screw M5×8
8 103040132 Flat washer 5
9
103202811
Connecting bracketⅠ
10 103020104 Bolt M12×35
11 103040110 Flat washer12
12 103040044 Spring washer12
13
103202812
Connecting bracketⅡ
14 103040123 Flat washer10
15 103040122 Spring washer10
16 103020120 Bolt M10×20
17
103200699
Bushing2520
18
103010429
ScrewM4×25
19 103201545 Bracket
20
102100075 Limit switch
21
103202817 Inner top beam
22 103202818 Outer top beam
23 103020123 Anchor Bolt M18×160
24
103060342
Pin 3X26
25 201011170 Long rod
26
201011172
Long rod supporting axle
27 201011257
Bushing Ⅱ
28 103203017 Pulley
29
103050035
Returning ring 25
30
103200967 Symmetric axle
31 201011258
BushingⅠ
32 103260257 Steel cable
34 103020190 Screw M6×10
35
103202810
TLT235SC（U）bracket of power unit
101
Power unit
102
104120136 HP Hose L=880
103100170
Fitting M14×1.5（For domestic）
103
103100171
Fitting G1/4〞（For imported）
104 104120096 HP Hose L=5370
