Launch TLT235、TLT240 Economical Two-post User’s Manual
35
221
103020093
Screw M8×16
222
201020500
Steel cable
223
103030131
Nut M16
224 103040159 Spring washer16
225
103040136
Flat washer16
226 103110061 Spring
227
103202345
Safety block
228 103010471 ScrewM8×40
229 103110060 Spring
201021653 TLT235SBPower side column
301
201024751 TLT240SBPower side column
201021652
TLT235SBOffside column
302
201020554
TLT240SBOffside column
103202810
TLT235SB Bracket 0f power unit
303
103202906
TLT240SB Bracket 0f power unit
304
103010326 Screw M6×12
305 103040133 Flat washer 6
306 103040140 Spring washe6
307
201020729
Floor plate
308 103202821 Floor plate cover
201021655 TLT235SB Top plate assembly
309
201024764 TLT240SB Top plate assembly
311
103203017 Top pulley
312
103200699 Bushing 2520
313
103050031 Retaining ring 25
314
103040176 Washer
317
103040110 Flat washer 12
318
103040044 Spring washer 12
319
103020104 Bolt M12×35
320
103040123 Flat washer 10
321 103040122 Spring washer 10
322
103020038 Bolt M10×25
323
103200962
Steel cable
324 103020123 Anchor bolt M18×160
325 103201071 Cover of hose
326 103010432 Screw M5X12
327 103040132 Washer5
401
Power unit
402
103100170 Fitting
403
104120076 HP Hose
404 103100140 Throttle joint
