LAUNCH X-431 PRO Series User Manual
29
Fig. 5-24
•
Combine
: This option is mostly used in graph merge status for data
comparison. In this case, different items are marked in different colors
(maximum 4 items can be displayed on the same screen simultaneously).
If the graph is more than one page, swipe the screen from the left to jump
to the next page.
•
Value
: Switches the current graph display mode to Value display mode.
•
Report
: To save the current data in text format. All reports are saved under
the tab “Diagnostic Report” in “My Report” from “Personal Center” menu.
For details on report operations, please refer to Chapter 9.1 “User Info”.
•
Record
: Tap to start recording diagnostic data for future playback and
analysis. The saved file follows the naming rule: It begins with vehicle type,
and then the record starting time and ends with .x431 (To differentiate
between files, please configure the accurate system time). The file is
stored in “My Report” under “User Info” menu.
