DescriptionofEachPart
3
Chapter1OVERALLDESCRIPTIONSK4/K8
OnlyforK8
8.Pocket5
9.Pocket6
10.Pocket7
11.Pocket8
4.Pocket1
5.Pocket2
6.Pocket3
7.Pocket4
12.OperationPanel
13.START/STOPSW
14.NotePressSW
17.NotePress
15.RejectPocket
19.MainSW
20.Hopper
21.DustTray1
18.NoteGuide
2.StatusLED
3.Sub-Display
1.PocketLED
16.RejectPocketLED
