LAUREL K4 - Feed Unit

Howtoremovejamnotes
61
Chapter3IFANERROROCCURSK4/K8
FeedUnit
STEP-1
OpentheFrontDoorbythehandle.
OnlyforK4 OnlyforK8
STEP-2
Removeremainednote by
openingtheTransportationPath
1.
HoldLever1tounlockthe
TransportationPath1toopen.
2.
Removeremainednote.
Ifthenoteareblocked,turnthe
knobA.Thenremoveit.
Lever1
KnobA
Toremove
anote.
