LAUREL LAUREATE 2 Series User Manual

- 26 -
KEYSTROKES FOR SETUP
If the MENU key does not work, see Section 9 “Enabling & Locking Out Menu Items.”
Press Menu
Select Key
Press Digit
Select Key
Press Value Select
Key
_InPut
Selection of signal
input type & range.
Needs to reflect
jumper settings.
_AC U
AC Volts
__0.2U __2.0U _20.0U 200.0U 600.0U
0.2, 2, 20, 200, 600V FS
_AC A U
AC Amps
__2.0a _20.0a _200.0a _5.0A
2, 20, 200 mA, 5A FS
SEtuP
Meter Setup
00_00
Display selection with
scale factor of 1
0 4-1/2 digits (±20,000)
1 5-digit remote display (±99,999)
2 4-1/2 digits, counts by 10 (±20,000)
3 3-1/2 digits (±2,000)
00 _00
Power line frequency
0 Noise minimized for 60 Hz
1 Noise minimized for 50 Hz
00_ 00
Scaling method
0 Scale and offset method
1 Coordinates of 2 points method
2 Reading coordinates of 2 points method
00_00
Rear panel control
inputs 1 & 2.
Connections
True = logic 1 (0V or
tied to digital ground)
False = logic 0 (5V or
open)
0 1 = Reset, 2 = Meter Hold
1 1 = Function Reset 2 = Pk or Valley Disp.
2 1 = Meter Hold 2 = Pk or Valley Disp.
3 1 = Meter Hold 2 = Tare
4 1 = Peak or Valley 2 = Tare
5 1 = Tare 2 = Reset
6 1 = 0, 2 = 0, decimal point 1= XXXXX
1 = 1, 2 = 0, decimal point 1 = XXXX.X
1 = 0, 2 = 1, decimal point 1 = XXX.XX
1 = 1, 2 = 1, decimal point 1 = XX.XXX
7 1 = 0, 2 = 0, decimal point 2 = XXXX.X
1 = 1, 2 = 0, decimal point 2 = XXX.XX
1 = 0, 2 = 1, decimal point 2 = XX.XXX
1 = 1, 2 = 1, decimal point 2 = X.XXXX
8 1 = Function Reset 2 = Display Blank
9 1 = Hold 2 = Display Blank
A 1 = Peak or Valley 2 = Display Blank
B 1 = Tare 2 = Display Blank
C 1 = Valley Display 2 = Peak Display
D 1 = Tare 2 = Tare Reset
Both inputs 1 and 2 set to 1 for selections
2, 4, A, C = Function Reset (fast, 20 msec).
Both inputs 1 and 2 set to 1 for selections
0, 1, 3, 5, 8, 9, B, D = Meter Reset (slow,
2 sec, same as removing & reapplying
power).
