LAUREL LAUREATE 2 Series User Manual

- 27 -
Press Menu
Select Key
Press Digit
Select Key
Press Value Select
Key
ConFG
Meter
Configuration
000_0
Operation as a rate of
change meter.
Extended meter only.
0 Not rate of change
1 Rate x 0.1
2 Rate x 1
3 Rate x 10
4 Rate x 100
5 Rate x 1000
6 Rate x 10000
00 _ _0
Operation of front
panel PEAK button
and rear connector for
Peak or Valley Display
0 Peak Display. Also selects “Peak” in
“Peak or Valley” at connector above.
1 Valley Display. Also selects “Valley” in
“Peak or Valley” at connector above.
2 Peak (1st push), Valley (2nd push)
3 Front panel Tare
000 _0
Auto-tare
0 Meter comes up in normal run mode.
1 Meter comes up in auto-tare mode.
000_ 0
Extended meter only.
0 Linear input
1 Custom curve linearization
FiLtr
Filtering
00000
Alarm filtering
0 Unfiltered output
1 Filtered output
00000
Peak & Valley filtering
0 Unfiltered Peak & Valley
1 Filtered Peak & Valley
00000
Display filtering
0 Display 16-reading batch average every
17 readings. Updates display 3.5 times/
sec at 60 Hz, 3.0 times/sec at 50 Hz.
1 Display per input signal filter setting
below
00000 Adaptive filter
threshold
0 Low adaptive filter threshold level
1 High adaptive filter threshold level
00000
Input signal filter
setting
Can be applied to dis-
play, setpoint, analog
output, data output.
0 Autofilter. Time constant set by meter.
1 Batch average of 16 readings
2 Moving average, 0.08 sec time constant.
3 Moving average, 0.15 sec time constant
4 Moving average, 0.3 sec time constant.
5 Moving average, 0.6 sec time constant.
6 Moving average, 1.2 sec time constant.
7 Moving average, 2.4 sec time constant.
8 Moving average, 4.8 sec time constant.
9 Moving average, 9.6 sec time constant.
A Unfiltered. Readings updated at 60/sec
at 60 Hz, 50/sec at 50 Hz.
dEc.Pt
Decimal point
selection
d.dddd
Decimal point flashes.
d.dddd dd.ddd ddd.dd dddd.d ddddd.
.ddddd
