LAUREL LAUREATE 2 Series User Manual

- 36 -
KEYSTROKES FOR SETUP
If the MENU key does not work, see Section 9 “Enabling & Locking Out Menu Items.”
Press Menu
Select Key
Press Digit
Select Key
Press Value Select
Key
_InPut
Selection of signal
input type & range.
Need to reflect
jumper setting.
_-rtd_
RTD
.. d °F- Pt100 RTD, DIN alpha .00385, °F
.. d °C. Pt100 RTD, DIN alpha .00385, °C
.. A °F- Pt100 RTD, ANSI alpha .003902, °F
.. A °C- Pt100 RTD, ANSI alpha .003902, °C
. ni °F - Ni120 RTD, alpha .00672, °F
..ni °C- Ni120 RTD, alpha .00672, °C
.Cu °F- Cu10 RTD, alpha .00427, °F
.Cu °C- Cu10 RTD, alpha .00427, °C
OHnnS
Ohmmeter
Set decimal point
under dEc.Pt
.. 20- 0 to 20.000 ohms
.. 200. 0 to 200.00 ohms
..2000- 0 to 2000.0 ohms
.20000 0 to 20000 ohms
200.00 0 to 200.00 kohm
SEtuP
Meter Setup
00_00
Display selection with
scale factor of 1.
0 0.1° RTD or 4-1/2 digits for ohms
1 5-digit remote display (±99,999)
2 0.01° RTD, 4-1/2 digit ohms count by 10
3 1° RTD or 3-1/2 digits for ohms
00 _00
Power line frequency
0 Noise minimized for 60 Hz
1 Noise minimized for 50 Hz
00_ 00
Scaling method
0 Scale and offset method (RTD & ohms)
1 Coordinates of 2 points (ohms)
2 Reading coordinates of 2 points (ohms)
00_00
Rear panel control
inputs 1 & 2:
True = logic 1 (0V or
tied to digital ground)
False = logic 0 (5V or
open)
0 1 = Reset, 2 = Meter Hold
1 1 = Function Reset, 2 = Peak or Valley
2 1 = Hold, 2 = Peak or Valley Display
3 1 = Hold, 2 = Tare
4 1 = Peak or Valley Display, 2 = Tare
5 1 = Tare, 2 = Reset
6 1 = 0, 2 = 0, decimal point 1= XXXXX
1 = 1, 2 = 0, decimal point 1 = XXXX.X
1 = 0, 2 = 1, decimal point 1 = XXX.XX
1 = 1, 2 = 1, decimal point 1 = XX.XXX
7 1 = 0, 2 = 0, decimal point 2 = XXXX.X
1 = 1, 2 = 0, decimal point 2 = XXX.XX
1 = 0, 2 = 1, decimal point 2 = XX.XXX
1 = 1, 2 = 1, decimal point 2 = X.XXXX
