LAUREL LAUREATE 2 Series User Manual

- 37 -
Press Menu
Select Key
Press Digit
Select Key
Press Value Select
Key
SEtuP
Meter Setup
(continued)
00_00
Control inputs 1 & 2
(continued)
8 1 = Function Reset 2 = Display Blank
9 1 = Hold 2 = Display Blank
A 1 = Peak or Valley 2 = Display Blank
B 1 = Tare 2 = Display Blank
C 1 = Valley Display 2 = Peak Display
D 1 = Tare 2 = Tare Reset
Both inputs 1 and 2 set to 1 for selections
2, 4, A, C = Function Reset (fast, 20 msec).
Both inputs 1 and 2 set to 1 for selections
0, 1, 3, 5, 8, 9, B, D = Meter Reset (slow, 2
sec, same as removing & reapplying
power).
ConFG
Meter
Configuration
00000 Operation as a
rate of change meter.
Extended meter only.
0 Not rate of change 3 Rate x 10
1 Rate x 0.1 5 Rate x 1000
2 Rate x 1 6 Rate x 10000
00000
Operation of front
panel PEAK button
and rear connector for
Peak or Valley Display
0 Peak Display. Also selects “Peak” in
“Peak or Valley” at connector above.
1 Valley Display. Also selects “Valley” in
“Peak or Valley” at connector above.
2 Peak (1st push), Valley (2nd push)
3 Front panel Tare
00000
Auto-tare selection
0 No auto-tare
1 Auto-tare
00000
RTD or Ohms wiring
RTD Ohms
00 3 or 4 wire 3 or 4 wire
01 Not allowed Custom curve
10 2-wire read 2-wire read
11 2-wire short 2-wire short
FiLtr
Filtering
00000
Alarm filtering
0 Unfiltered output
1 Filtered output
00000
Peak & Valley filtering
0 Unfiltered Peak & Valley
1 Filtered Peak & Valley
00000
Display filtering
0 Display 16-reading batch average every
17 readings. Updates display 3.5 times/
sec at 60 Hz, 3.0 times/sec at 50 Hz.
1 Display per input signal filter setting
below
00000 Adaptive filter
threshold for all filters
0 Low adaptive filter threshold level
1 High adaptive filter threshold level
