FiLtr
Filtering
(continued)
00000
Input signal filter
setting
Can be applied to dis-
play, setpoint, analog
output, data output.
0 Autofilter
1 Batch average, 16 readings
2 Moving average, 0.08 sec.
3 Moving average, 0.15 sec.
4 Moving average, 0.3 sec.
5 Moving average, 0.6 sec.
6 Moving average, 1.2 sec.
7 Moving average, 2.4 sec.
8 Moving average, 4.8 sec.
9 Moving average, 9.6 sec.
A Unfiltered. Updates at 60/sec at 60 Hz,
50/sec at 50 Hz.
dEc.Pt
Decimal point
selection
d.dddd
Decimal point flashes
if ohms are selected
under _InPut
d.dddd dd.ddd ddd.dd dddd.d ddddd.
.ddddd
0.0000 0.0000 0.0000
0.0000 0.0000 0.0000
Select digit then dec
pt
Select -9 thru 9 for first flashing digit, 0 thru
9 for flashing other digits. Then press key
to move flashing decimal point.
0.0000 0.0000 0.0000
0.0000 0.0000
Select digit to flash.
Select -9 thru 9 for flashing first digit, 0 thru
9 for other flashing digits. Use offset for
display in Rankine or Kelvin. Decimal point
location is selected by dEC.Pt.
Option board dependent menu items
ALSEt. ALS34 dEU1H dEU2H dEU1b dEU2b dEU3H DEU4H DEU3b DEU4b
Menu items related to alarm setup These will only appear if a relay board is detected. If
so, see Section 16.
AnSEt. An Lo. An Hi..
Menu items related to analog output setup. These will only appear if an analog output
board is detected. If so, see Section 17.
SEr 1. SEr 2. SEr 3. SEr 4. _Addr
Menu items related to communications. These will only appear if an RS232, RS485, USB
or Ethernet board is detected. If so, see Section 18.
Loc 1. Loc 2. Loc 3.
Menu items used to enable or lock out (hide) other menu items. Loc menu items may in
turn be locked out by a hardware jumper on the power supply board. See Section 9.
