LAUREL LTE Series - Page 45

- 45 -
Input Signal Noise Rejection
CMV, DC to 60 Hz ......................................................................................................... 250V RMS
CMR, DC to 60 Hz .............................................................................................................. 130 dB
NMR at 50/60 Hz ............................................................................. 90 dB with no digital filtering
Input filtering ...................................... Programmable digital time constants from 80 ms to 9.6 s
Overvoltage Protection
Voltage input ranges of 2V and above (AC or DC) ......................................................... 600 Vrms
Voltage input ranges of 200 mV (AC or DC), load cell, thermocouple, RTD .................. 100 Vrms
DC Volts, DC Amps, Process, and DC Ratio Input
Range
Input Resistance
Input Error
±200.00 mV
±2.0000 V
±20.000 V
±200.00 V
1 GΩ
1 GΩ
10 MΩ
10 MΩ
0.01% of full scale
± 2 counts
±300.0 V & ±600.0 V*
10 MΩ
±0.4 V
±2.0000 mA
±20.000 mA
±200.00 mA
100 Ω
10 Ω
1 Ω
0.01% of full scale
± 2 counts
±5.000 A
0.01 Ω
±10 mA
True AC RMS Volts & Amps
Range
Input Resistance
Input Error
200.00 mV
2.0000 V
20.000 V
200.00 V
1 MΩ
1 MΩ
1 MΩ
1 MΩ
0.03% of full scale
± 2 counts
300.0 V & 600.0 V*
1 MΩ
±0.8 V
2.0000 mA
0.000 mA
200.00 mA
100 Ω
10 Ω
1 Ω
0.03% of full scale
± 2 counts
5.000 A
0.01 Ω
±20 mA
Coupling ................................................................................. AC or AC + DC (jumper selectable)
AC Frequency Range ............................................................... 10 Hz to 15 kHz, crest factor to 3.0
* 600V ranges are not ETL certified.
