Laversab 6600 - Page 24

17
2-output format
1 4 2
13 14
Units: knots Feet/min Feet
Actual: M 5.2 0 1005 M
Target: 20.0 3000 0
5 9 8 12 6 10
3-output format
3 15
Units: knots Feet Feet
Actual: M 5.2 1006 M 1005 M
Target: 20.0 0 0
7 11
1. Pt units
2. Ps1 units
3. Ps2 units (3-output format only)
4. Ps1 Rate units (2-output format only)
5. Pt Actual value
6. Ps1 Actual value
7. Ps2 Actual value (3-output format only)
8. Ps1 Rate Actual value (2-output format only)
9. Pt Target value
10. Ps1 Target value
11. Ps2 Target value (3-output format only)
12. Rate Target value (2-output format only)
13. Pt mode
14. Ps1 mode
15. Ps2 mode (3-output format only)
Figure 3.2
