APPENDIX B
SPECIFICATIONS
Ps1 Output
Pressure function
range: 0.1 to 42 inHg
resolution: 0.001 inHg
accuracy: 0.002 inHg
Altitude function
range: -4000 ft. to 60,000 ft.
resolution: 1 foot
accuracy: 2 ft. @ 0 ft.
6 ft. @ 35,000 ft.
12 ft. @ 50,000 ft.
Climb function
range: 0 ft/min to 25,000 ft/min
resolution: 1 ft/min
accuracy: 1% of rate of climb
Pt Output
Pressure function
range: 0.1 to 60 inHg
resolution: 0.001 inHg
accuracy: 0.003 inHg
Airspeed function
range: 0 to 650 knots
resolution: 0.1 knots
accuracy: 0.5 knots @ 50 knots
0.25 knots @ 100 knots
0.05 knots @ 650 knots
Mach function
range: 0.0 to 3.0 Mach
resolution: 0.001 Mach
accuracy: 0.001 above 0.2 Mach
Ps2 Output
range: 0.1 to 42 inHg (Diff. to Ps1: +/-30.0 inHg)
resolution: 0.001 inHg
accuracy: 0.002 inHg
Power requirement
90-260 VAC, 47-440 Hz., 250 VA
Interfaces
RS232
Dimensions & weights
Main unit: 22” x 14” x 9” / 45 lbs
Remote unit: 7” x 8” x 2” / 1 lb.
Environmental specs:
Operating temp. 0
o
to50
o
C
Storage temp. -25
o
to 75
o
C
Humidity: 5 to 95% non-condensing
