3.2.1 DISPLAYED PARAMETERS
There are 15 basic parameters of importance while using the 6600. Each of these parameters is
displayed on the Main Screen either on the 2-output format or on the 3-output format. The 15
parameters are indicated in the 2-output and 3-output formats shown in Figure 3.2 above.
Each parameter is explained in detail below and highlighted in a sample screen.
Parameter 1. Pt Units: Unit of measurement for displaying the Pt output. This parameter is
accessible in both 2-output and 3-output formats. Normally, the Pt unit used is ‘Knots’ for
displaying airspeed. Other possible units for displaying the Pt output are shown in section
3.2.3, which also explains how to select a particular unit. The currently selected Pt unit is
shown on the first line of the display (as shown below). The two values (101.2 and 20.0) that
appear below it are in these units.
2-output format
Units: knots Feet/min Feet
Actual: M 101.2 3500 1005 M
Target: 20.0 3000 0
Parameter 2. Ps1 Units: Unit of measurement for displaying the Ps1 output. This
parameter is accessible in both 2-output and 3-output formats. Normally, the Ps1 unit used is
‘Feet’ for displaying altitude. Other possible units for displaying the Ps1 output are shown
in section 3.2.3, which also explains how to select a particular unit. The currently selected Ps1
unit is shown on the first line of the display (as shown below). The two values (1005 and 0)
that appear below it are in these units.
2-output format
Units: knots Feet/min Feet
Actual: M 101.2 3500 1005 M
Target: 20.0 3000 0
Parameter 3. Ps2 Units: Unit of measurement for displaying the Ps2 output. This
parameter is accessible only on the 3-output format. There are eight possible selections for Ps2
units. These are shown in section 3.2.3, which also explains how to select a particular unit.
The currently selected Ps2 unit is shown on the first line of the display (as shown below). The
two values (1006 and 0) that appear below it are in these units.
