Laversab 6600 - Page 70

63
Model: 6600 Serial#: 77123
Full scale: Ps: 38 inHg
Pt: 60 inHg
Last Calibrated date: June 25, 2007 Next Calibration due: June 25, 2009
_______________________________________________________________________
CALIBRATION RESULTS
Ps1 Output
TEST POINT AS FOUND AS LEFT DEVIATION
inHg inHg inHg
1. Vacuum 1.001 1.000 0.001
2. Fullscale 38.002 38.000 0.002
Ps2 Output
TEST POINT AS FOUND AS LEFT DEVIATION
inHg inHg inHg
1. Vacuum 1.000 1.000 0.000
2. Fullscale 38.001 38.000 0.001
Pt Output
TEST POINT AS FOUND AS LEFT DEVIATION
inHg inHg inHg
1. Vacuum 1.001 1.000 0.001
2. Fullscale 60.002 60.000 0.002
_______________________________________________________________________
VERIFICATION RESULTS
Ps1 Output Ps2 Output Pt Output
APPLIED DISPLAYED APPLIED DISPLAYED APPLIED DISPLAYED
inHg inHg inHg inHg inHg inHg
1.000 1.000 1.000 1.000 1.000 1.000
4.000 4.000 4.000 4.000 6.000 5.999
8.000 8.000 8.000 7.999 12.000 11.999
12.000 12.000 12.000 11.999 18.000 18.000
15.000 15.000 15.000 15.000 24.000 24.000
19.000 19.001 19.000 19.000 30.000 30.000
23.000 23.001 23.000 23.000 36.000 36.000
27.000 27.000 27.000 27.001 42.000 42.001
30.000 30.000 30.000 30.000 48.000 48.002
34.000 34.000 34.000 34.000 54.000 54.001
38.000 38.000 38.000 38.000 60.000 60.000
_______________________________________________________________________
Calibrated by: Date: June 25, 2008
Figure 6.1 Sample calibration sheet
