17
ASSEMBLY
Fig. 5
3. Align the cover and base of the grass collection bag at the front. Clip the two halves together,
starting at the front and then moving to the sides (Fig. 5).
4.Slide the tongue into the front section of the grass collection bag and ensure it is securely placed (Fig. 6).
5.The completely assembled grass collection bag is as shown as below (Fig. 7).
Fig. 6 Fig. 7
