49
GEAR HEAD AND SPOOL
Fig. 103
■ Hook the folded end of the cutting line onto either of the slots in the spool (Fig. 104).
■ Wind the line onto the spool. Wind the line in the “Wind Cord” arrow direction indicated on the spool
(Fig. 104).
■ Place the ends of the line in the two opposite parking slots of the spool, leaving some of the line out
(Fig. 105).
NOTE:
Always clean the main spool cover and trimmer head housing before reassembling the trimmer
head.
NOTE:
Always clean the trimmer head before replacing the spool.
■ Check the spool cover, spool, and spool head for wear and replace parts if necessary. Install the
spool in the spool cover and replace as described in the Spool Replacement section.
NOTE:
Only use the appropriate cutting line specied in this manual.
Fig. 105Fig. 104
Winding Direction
