PARTS AND FEATURES
NPTGSP2517A PARTS LIST
Key
Number
Application Description Quantity
1 321007101 Cleva 25cc 2-Cycle Engine 1
2 321007102 Throttle-body & Starter Set 1
2.1 321007103 Throttle-body Set 1
2.2 321007104 Starter Set 1
2.2.1 321001105 Micro Switch 1
2.2.2 321007105 Starter Switch Assembly 1
2.2.3 321007106 Stop Switch Set 1
2.2.4 321007107 PCB Assembly 1
3 321008101 Connection Cover Assembly 1
4 321008102 Aluminum Upper Shaft 1
5 141004102 Cable Clamp 2
6 321001109 Handle Spacer 2
7 321008103 Assist Handle Assembly 1
8 321008104 Aluminum Connector Assembly 1
9 321008105 Aluminum Lower Shaft 1
10 321008106 Debris Guard 1
10.1 321008107 Small Debris Guard Assembly 1
10.2 321008108 Large Debris Guard Assembly 1
11 321008109 Spool Head Assembly 1
11.1 321008110 Spool Spring 1
12 321008111 Gear Box 1
12.1 321008112 Screw M5*16 3
12.2 321008113 Cover Plate 1
13 321007116 7.2V 1.3Ah Lithium-Ion Battery 1
14 321001127 Charger 1
15 321001128 Shoulder Strap Clasp (Available Separately) 1
16 221003102 Shoulder Strap (Available Separately) 1
17 321004122 M5 Hexagon Socket Wrench 1
18 321004121 M6 Hexagon Socket Wrench 1
19 321007118 Quincunx Wrench 1
20 321007119 Socket Wrench 1
