LawnMaster NPTGSP2517A Service Manual

9
PARTS AND FEATURES
NPTGCP2517B PARTS LIST
Key
Number
Application Description Quantity
1 321007101 Cleva 25cc 2-Cycle Engine 1
2 321007102 Throttle-body & Start Set 1
2.1 321007103 Throttle-body Set 1
2.2 321007104 Starter Set 1
2.2.1 321001105 Micro Switch 1
2.2.2 321007105 Starter Switch Assembly 1
2.2.3 321007106 Stop Switch Set 1
2.2.4 321007107 PCB Assembly 1
3 321007108 Connection Cover Assembly 1
4 321007109 Aluminum Upper Shaft 1
4.1 321007110 Shaft Connection Sleeve 1
5 141004102 Cable Clamp 2
6 321007111 Handle Spacer 2
7 321007112 Assist Handle 1
8 321007113 Lower Curved Shaft 1
9 321007114 Spool Head Assembly 1
9.1 321007115 Spool Spring 1
10 321002105 Debris Guard 1
11 321007116 7.2V 1.3Ah Lithium-Ion Battery 1
12 321001127 Charger 1
13 321004122 M5 Hexagon Socket Wrench 1
14 321007118 Quincunx Wrench 1
15 321007119 Socket Wrench 1

LawnMaster NPTGSP2517A Specifications

General

Brand	LawnMaster
Model	NPTGSP2517A
Category	Trimmer
Language	English
