LB-Link BL-M8723DU1 - 3.3 RF Specifications

4
802.11n HT20 MCS0 MCS7
Supply current Typ. Max. Typ. Max.
TX mode 250 260 185 200
Rx mode 89 91 92 96
802.11n HT40 MCS0 MCS7
Supply current Typ. Max. Typ. Max.
TX mode 240 250 180 190
Rx mode 90 92 95 99
3.3 RF Specifications
TX Constellation Error(EVM)
802.11b: <-20dB@11Mbps
802.11g:<-28dB@54Mbps
802.11n-HT20: <-28dB@72.2Mbps
802.11n-HT40:< -28dB@150Mbps
Receiver Minimum Input Sensitivity@PER
1Mbps: -92dBm@PER<8%;
11Mbps:-85dBm@PER<8%;
54Mbps:-72dBm@PER<10%;
150Mbps:-66dBm@PER<10%;
BT: -89dBm@1Mbps -85dBm@2Mbps
-83dBm@3Mbps
