FLAGS AND LED INTERPRETATION

FLAGS INTERPRETATION

FLAG

DESCRIPTION

Alarm max/min activated

- Interruption coils circuit

- Segnal error

- Empty pipe

Calibration running

Simulation

Pulse output saturation

(reduce TIME PULSE )

LED

LED INTERPRETATION

PERMANENT LIGHT: initialization

FLASHING LIGHT (1 sec.): normal function

FLASHING LIGHT (<1 sec.): alarm on

The LED signals the real alarm status only if the display visualizes

one of the visualization pages

ATTENTION: The LED is not visible in the panel version of the

converter
