F503 0
F504 1
F505 0.0
F506 10
F507 10
F510 10.0
F511 10.0
F512 0
F513 0.0
● Protection Parameters
F601 150
F602 0
F603 0
F604 1.0
F605 0
F607 60
F608 1
F610 0
F611 0
F612 0
F613 0
F615 0
F616 150
F618 0.5
F619 10
F621 610
F626 *1
F627 1
F633 0
F634 3
F669 0
F676 0
F677 800
F691 1
F692 0
● Operation Panel Parameters
F700 0
F701 1
F702 0.00
F705 1
F706 0.00
F707 0.00
F708 0
F710 0
F719 1
F721 0
Title Function Adjustment range
Default setting
Note
Acceleration/
deceleration
2 pattern
Selecting an
acceleration/
deceleration pattern
Acceleration/deceleration 1
and 2 switching frequency
S-pattern lower-limit
adjustment amount
S-pattern upper-limit
adjustment amount
Acceleration time 3
Deceleration time 3
Acceleration/
deceleration
3 pattern
Acceleration/deceleration 2
and 3 switching frequency
0: Linear,
1: S-pattern 1,
2: S-pattern 2
1:
Acceleration/deceleration 1 pattern
2:
Acceleration/deceleration 2 pattern
3:
Acceleration/deceleration 3 pattern
0.0-
UL
(Hz)
0-50%
0-50%
0.0-3200 (s)
0.0-3200 (s)
1: Linear,
2: S-pattern 1,
3: S-pattern 2
0.0-
UL
(Hz)
Title Function Adjustment range
Default setting
Note
Annual average
ambient temperature
(calculation for life
alarms)
Logic output/pulse
train output selection
(DRV-OM)
Pulse train output
function selection
(DRV-OM)
Maximum numbers
of pulse train
Inclination
characteristic of
analog output
Bias of analog output
1: -10 ~ +10°C
2: 11~20°C
3: 21~30°C
4: 31~40°C
5: 41~50°C
6: 51~60°C
0: Logic output
1: Pulse train output
0: Output frequency
1: Output current
2: Set frequency
3: DC voltage
4:
Output voltage command value
5: Input power
6: Output power
7: Torque
8: Torque current
9: Motor cumulative load factor
10:
Inverter cumulative load factor
11: Braking reactor cumulative
load factor
12: Frequency setting value
(after PID)
13: VRF Input value
14: VRF2 Input value
15: Fixed output 1
(Output current: 100%)
16: Fixed output 2
(Output current: 50%)
17: Fixed output 3 (Other than
the output current: 100%)
500-1600 (PPS)
0:
Negative inclination (downward slope)
1:
Positive inclination (upward slope)
0-100%
Title Function Adjustment range
Default setting
Note
Prohibition of change
of parameter setting
Current/voltage
display mode
Frequency free unit
magnification
Inclination
characteristic of free
unit display
Bias of free unit
display
Free step 1
(pressing a panel
key once)
Free step 2 (panel
display)
Standard monitor
display selection
Canceling of operation
command when standby
terminal (ST) is turned off
Selection of operation
panel stop pattern
0: Permitted,
1: Prohibited
0: %
1: A (ampere)/V (volt)
0.00: Free unit display disabled
(display of frequency)
0.01-200.0 (times)
0:
Negative inclination (downward slope)
1:
Positive inclination (upward slope)
0.00-
FH
(Hz)
0.00: Disabled
0.01-
FH
(Hz)
0: Disabled
1-255
0: Operation frequency
(Hz/free unit)
1: Frequency command
(Hz/free unit)
2: Output current (%/A)
3: Inverter rated current (A)
4: Inverter load factor (%)
5: Output power (kW)
6: Frequency command after
PID control (Hz/free unit)
7: Optional item specified from
an external control unit
0: Operation command
canceled (cleared)
1:
Operation command retained
0: Slowdown stop
1: Coast stop
Title Function Adjustment range
Default setting
Note
Stall prevention level 1
Inverter trip retention
selection
Emergency stop
selection
Emergency DC
braking time
Output phase failure
detection mode
selection
Motor
150%-overload
time limit
Input phase failure
detection mode selection
Small current
trip/alarm selection
Small current detection current
Small current detection time
Detection of output
short-circuit during
start-up
Over-torque
trip/alarm selection
Over-torque
detection level
Over-torque
detection time
Over-torque
detection level
hysteresis
Cumulative operation
time alarm setting
Overvoltage limit
operation level
Undervoltage
trip/alarm selection
*3
Trip at VRF low level
input mode
10-199 (%/A)
200 (Deactivated)
0: Cleared if power is turned off
1:
Retained even if power is turned off
0: Coast stop
1: Slowdown stop
2: Emergency DC braking
0.0-20.0 (s)
0: Disabled
1: At start-up (Only one time
after power is turned on)
2: At start-up (each time)
3: During operation
4:
At start-up + during operation
5:
Detection of cutoff on output side
1-2400 (s)
0: Disabled, 1: Enabled
0: Alarm only
1: Tripping
0-100 (%)
0-255 [sec]
0: Each time (standard pulse)
1: Only one time after power is
turned on (standard pulse)
2: Each time (short-time pulse)
3: Only one time after power is
turned on (short-time pulse)
0: Alarm only
1: Tripping
0-250 (%)
0.0-10.0 [sec]
0-100 (%)
0.0-9.999 (100 hrs)
100-150%
0: Alarm only (detection level
below 60%)
1: Tripping (detection level
below 60%)
2: Alarm only (detection level
below 50%, DC reactor
needed)
0: Disabled
1-100%
*1: Default setting of the parameter differs by each inverter capacity. Refer to "Default settings by Inverter Rating" table on page 19 for actual values.
*2: Unit displayed may be selected by parameter F701 (Unit selection).
*3: Always implement DC reactor (optional) when setting parameter F627 (Undervoltage trip/alarm selection) to "2 (detection level below 50%)."
