■ Input/Output Terminal Functions
Allocating the function numbers in the table
below to the parameters F110~F118 (input terminal selection) and F130~F138 (output
terminal selection) will assign various roles to contact input/output terminals.
●Table of Input Terminal Functions
Function No.
Function
1 Standby terminal
2 Forward run command
3 Reverse run command
4 Jog run mode
5 Acceleration/deceleration 2 pattern selection
6 Preset-speed command 1
7 Preset-speed command 2
8 Preset-speed command 3
9 Preset-speed command 4
10 Reset command
11 Trip stop command from external input device
12 Switching of command mode and frequency setting mode
13 DC braking command
14 PID control prohibited
15 Permission of parameter editing
16 Combination of standby and reset commands (No.1 + 10)
17
Combination of standby and command/frequency setting mode
switching (No.1 + 12)
18 Combination of forward run and jog run (No.2 + 4)
19 Combination of reverse run and jog run (No.3 + 4)
20
Combination of forward run and acceleration/deceleration 2 (No.2 + 5)
21
Combination of reverse run and acceleration/deceleration 2 (No.3 + 5)
22
Combination of forward run and preset-speed command 1 (No.2 + 6)
23
Combination of reverse run and preset-speed command 1 (No.3 + 6)
24
Combination of forward run and preset-speed command 2 (No.2 + 7)
25
Combination of reverse run and preset-speed command 2 (No.3 + 7)
26
Combination of forward run and preset-speed command 3 (No.2 + 8)
27
Combination of reverse run and preset-speed command 3 (No.3 + 8)
28
Combination of forward run and preset-speed command 4 (No.2 + 9)
29
Combination of reverse run and preset-speed command 4 (No.3 + 9)
30 Combination of forward run, preset-speed command 1 and
acceleration/deceleration 2 (No.2 + 5 + 6)
31 Combination of reverse run,
preset-speed command 1 and
acceleration/deceleration 2 (No.3 + 5 + 6)
32 Combination of forward run,
preset-speed command 2 and
acceleration/deceleration 2 (No.2 + 5 + 7)
33 Combination of reverse run,
preset-speed command 2 and
acceleration/deceleration 2 (No.3 + 5 + 7)
34 Combination of forward run, preset-speed command 3 and
acceleration/deceleration 2 (No.2 + 5 + 8)
35 Combination of reverse run, preset-speed command 3 and
acceleration/deceleration 2 (No.3 + 5 + 8)
36 Combination of forward run, preset-speed command 4 and
acceleration/deceleration 2 (No.2 + 5 + 9)
37 Combination of reverse run, preset-speed command 4 and
acceleration/deceleration 2 (No.3 + 5 + 9)
38 Frequency command forced switching to F207
39 No.2 Switching of V/F setting
40 No.2 motor switching (No.5 + 39 + 61)
41 Frequency UP signal input from external contacts
42 Frequency DOWN signal input from external contacts
43
Frequency UP/DOWN cancellation signal input from external contacts
44 Combination of frequency UP/DOWN cancellation and reset by
means of external contacts (No.10 + 43)
45
Inversion of trip stop command from external device (Inversion of No.11)
46 Thermal trip stop signal input from external device
47 Inversion of thermal trip stop command from external device
(Inversion of No.46)
48 Forced switching from remote to local control
49 Operation holding (stop of 3-wire operation)
50 Forced switching of command mode and terminal board command
51 Display cancellation of the cumulative power amount (kWh)
52 Forced operation (factory configuration required)
53 Fire-speed control
54 Inversion of standby terminal (Inversion of No.1)
55 Inversion of reset command (Inversion of No.10)
Function No.
Function
56 Combination of forward run and standby (No.1 + 2)
57 Combination of reverse run and standby (No.1 + 3)
58 Acceleration/deceleration 3 selection
59
Combination of forward run and acceleration/deceleration 3 (No.2 + 58)
60
Combination of reverse run and acceleration/deceleration 3 (No.3 + 58)
61 Forced switching of stall prevention level 2
62 Holding of RY-RC terminal output
63 Holding of OUT-OM terminal output
64 Cancellation (clearing) of operation
command from panel
●Table of Output Terminal Functions
Function No.
Function
0/1 Frequency lower limit/its inversion
2/3 Frequency upper limit/its inversion
4/5 Low-speed detection signal/its inversion
6/7 Designated frequency attainment signal
(completion of
acceleration/deceleration) /its inversion
8/9 Set frequency attainment signal/its inversion
10/11 Failure signal (trip output)/its inversion
12/13 Over-torque detection/its inversion
14/15 RUN&STOP/i
ts inversion
16/17 OL pre-alarm/its inversion
18/19 Braking resistor overload pre-alarm/its inversion
20/21 Over-torque detection pre-alarm/its inversion
22/23 Pre-alarm/its inversion
24/25 Small-current detection/its inversion
26/27 Significant failure/its inversion
28/29 Insignificant failure/its inversion
30/31 Ready for operation (including ST/RUN)/its inversion
32/33 Ready for operation (excluding ST/RUN)/its inversion
34/35 Frequency VRF2 selection/its inversion
36/37 Fault signal (put out also at the time of a
retry)/its inversion
38/39 Specified data output 1/its inversion
40/41 Specified data output 2/its inversion
42/43 Cumulative operation time alarm/its inversion
44/45 Calculation for life alarm/its inversion
46/47 Braking sequence output/its inversion
48/49 FR terminal input signal/its inversion
50/51 RR terminal input signal/its inversion
52/53 Signal in accordance of frequency command/its inversion
54/55 Undervoltage detection/its inversion
56~253 Invalid settings, always OFF (ignored)
254 Always OFF
255 Always ON
Note 1: Even-numbered functions are positive logic and odd-numbered functions
are negative logic for Functions 0~55.
