LCN 4600CS - 4630 CS;4640 CS Replacement Parts List Information

Page 19
4630CS/4640CS REPLACEMENT PARTS LIST INFORMATION
4630 - 30
ARM SET
SCREW
4630 - 3034
ROLLER
4630 - 73
END CAP
4630 - 141
TRACK
PLUG
4630 - 159
ARM
SHAFT
SCREW
4640 - 83
ARM SET SCREW
4640 - 79
ROD & SHOE
4640 - 3077
MAIN ARM
4642CS ARM PARTS
4630 - 3077T
ARM ASSY.
4631CS ARM PARTS
- 480
SHAFT
EXTENDER
PACKAGE
- 3454
MOTOR / CLUTCH
ASSY.
- 20 CONDUIT
COVER
-155G
DOOR
DECAL
When ordering replacement parts remember to specify Model (4630 or 4640)
in front on the desired part #. Also specify Color / Finish when required.
4630 - 3038
TRACK
ASSY.
- 3498-1
RIBBON CABLE
CONNECTOR
4630 - 61
SHAFT
SPACER
AUTOMATIC
DOOR
CAUTION
- 31 -1
END CAP
SCREW
- 3971
CYLINDER
ASSEMBLY
- 31 COVER
SCREW
- 334 - 2
BLANK
END CAP
- 3462
CONTROLLER
ASSEMBLY
- 3180
PCB
BOARD
ASSEMBLY
- 334CS
SWITCH
END CAP
- 3498-2
AC POWER
CABLE
- 31 MTG.
SCREW
- 72 COVER
4640 - 159
ARM
SHAFT
SCREW
