Page 9 of 19
TION
3.1 Refer to the appropriate wiring diagram for the Control Box (Page 19) or the diagram
supplied for custom applications.
Connect the following cables:
• Ground Cable (Ground the Operator properly with the earth from main supply)
• Hall Effect Cable (Do not wrap the Hall Effect Cable around the Motor Power Cable)
• Motor Power Cable (Do not wrap the Motor Power Cable around the Hall Effect Cable)
• Control Box Power Cable
3.2 Connect Activate, Safety, Key Switch, and lock accessories, as needed.
Refer to the accessory instructions for any accessories used.
Do not connect any remote activating device to the door unless it is located within
line of sight of the door.
3.3 When wiring is complete, proceed to Chapter 4: Arm and Cover Installation (Page 10)
3. WIRING
CAUTION
• Make sure all wires are properly dressed and secured to prevent interference
• Route all wiring away from moving parts, sharp edges, and heat sources
• Use copper conductors only
• Do not modify the factory wiring or connect into existing electrical circuits or devices
To Next Page
