PAGE 11

Typical Icom Mic Pinout

Likewise, a typical Icom mic pinout would be as follows. Again, check with your radio’s manual

to be sure. Not all radios are the same.

Number Name

1 Data In

2 GND

3 MIC

4 Mic GND

5 PTT

6 8V Switched

7 Up/Down

8 8V Output

Typical Icom Mic Pinout

Typical Yaesu Mic Pinout

A typical Yaesu mic pinout is shown below. Once again, please consult your radio owner’s

manual for exact details, and beware that some radio manufacturers number the RJ45 pins opposite

of the numbering on the SLS-2 pins.

Typical Yaesu Mic Pinout

Number Name

1 Down

2 Up

3 5V DC

4 MIC Gnd

5 MIC

6 PTT

7 GND

8 Fast Scan
