PAGE 5
Rear Panel
The rear panel of the SLS-2 features three RJ45 jacks. One is a common jack, and the other two
are the switched jacks. The front panel pushbutton alternately connects either Port 1 or Port 2 to the
Common Port. The DC power jack accepts 12 volts DC at 100 mA, center positive.
