RT-600 Operations Manual Version 1.0
8
Secure the RT-600 to a Mast
Your RT-600 is designed to be mounted on a mast or other similar support; a clamp
and U-bolt are provided for this purpose. Remove the nuts and clamp from the U-bolt.
Place the U-bolt around the mast, then slide the clamp over the threaded ends of the
U-bolt, so that the flat edge of the clamp faces away from the mast. Insert the
threaded ends of the U-bolt through the back of the mounting bracket at the top of the
RT-600. Thread the nuts back onto the U-bolt, and snug them up. Tighten only as
much as is required to keep the RT-600 from sliding down the mast; do not over-
tighten. Install with the mounting bracket up and the connectors down to help prevent
rainwater from leaking into the connectors.
The RT-600 is
intended to be
installed on a
ground-
mounted mast.
