Introduction

Photon II System Guide 3

Warning

Do not connect analog voltage signals exceeding

+40 Volts to the input channel or the system

electronics may be damaged.

Front view of the Photon II showing the BNC Connectors for Four Input Channels

Rear view of the Photon II showing the BNC connector forOutput/Tach-in and the

USB Cable Port.
