Installation Instructions
have output, this graphic symbol will be light.
14. The indicator of capacity of battery: When the battery
was in different capacity, the strip-type will show.
15. The indicator of charge status: When the controller is
charging, the symbol will be light, float charge will be
flash, no charging no display.
1) The controller should be installed well-ventilated place,
avoid direct sunlight, high temperature and do not
install in location where water can enter the controller.
2) Please select correct screw to fix the controller on the
wall or other platform. Screw M4 or M5, Screw cap
diameter less than 10mm.
3) Please reserve enough space between the wall and
controller, to allow for cooling and cable connection.
4) The mounting holes distance is 155.8mm*63mm,
diameter of the hole is 5mm.
