30
Unscrew the tank cap and remove it. (Fig. 8)
– Pour in the fuel carefully. Avoid spilling !
– Screw the tank cap on firmly by hand.
Fig.8
6.4 Filling with engine oil
1) Unscrew and remove the oil tank cap.
2) Gradually add good-quality engine oil. Allow the oil to settle.
3) Check the oil level frequently while filling. Wipe the oil dipstick clean; refit and tighten the
filler cap and then remove it again. The oil level must be within the min / max markings.
Add more oil if necessary. Do not overfill (Fig. 8).
Fig. 9
4) Wipe spilled oil with a soft cloth and reattach the oil tank cap.
7. OPERATION
Risk of device damage!
The device is supplied without motor oil.
ATTENTION! Before operating, you must fill it with motor oil.
WARNING! This product is not supplied with oil. However, for
manufacturing reasons it is possible that a small quantity may be left in the
ATTENTION ! oil tank (see ”Technical specifications”)!
max
min
