CS-D808 Closed Loop Stepper Drive User Manual
Page | 12
Appendix A. Leadshine CS-D808 Compatible Stepper Motors
The following Leadshine stepper motors with 1000-line encoders have been tested working with the CS-D808 closed
loop stepper drive.
Model
Frame Size
(NEMA)
Torque
(N.m / Oz-In)
Series
Length
(mm / inch)
Notes
CS-M23435
34
3.5 / 495
CS-M
95 / 2.20
0.551-inch (14-mm) shaft
CS-M23435-S
3.5 / 495
95 / 2.48
0.50-inch (12.7-mm) shaft
CS-M23445
4.5 / 637
109 / 2.76
0.551-inch (14-mm) shaft
CS-M23445-S
4.5 / 637
109 / 3.27
0.50-inch (12.7-mm) shaft
CS-M23445B
4.5 / 637
135 / 2.44
0.551-inch (14-mm) shaft, with
24VDC brake
CS-M23480
8.0 / 1132
127 / 3.03
0.551-inch (14-mm) shaft
CS-M23480-S
8.0 / 1132
127 / 3.82
0.50-inch (12.7-mm) shaft
CS-M23480B
8.0 / 1132
173 / 3.82
0.551-inch (14-mm) shaft, with
24VDC brake
CS-M23485
8.5 / 1202
147 / 4.13
0.551-inch (14-mm) shaft
CS-M23485-S
8.5 / 1202
147 / 4.13
0.50-inch (12.7-mm) shaft
CS-M23485B
8.5 / 1202
173 / 3.46
0.551-inch (14-mm) shaft, with
24VDC brake
CS-M234120
12.0 / 1698
158 / 4.29
0.551-inch (14-mm) shaft
CS-M234120B
12.0 / 1698
184 / 4.29
0.551-inch (14-mm) shaft, with
24VDC brake
ES-M23440
4.0 / 566
ES-M
73 / 2.87
0.551-inch (14-mm) shaft
ES-M23440-S
4.0 / 566
73 / 2.87
0.50-inch (12.7-mm) shaft
ES-M23480
8.0 / 1132
93 / 3.66
0.551-inch (14-mm) shaft
ES-M23480-S
8.0 / 1132
93 / 3.66
0.50-inch (12.7-mm) shaft
Note: all above stepper motors are mounted with 1000-line incremental encoders
