LR9101X Specifications Sheet Rev. 1.3
Protocol message
GGA(1s), GSA(5s), GSV(5s), RMC(1s),VTG(1s)
Output frequency
1 Hz
2.4. Mechanical specification
The Physical dimensions of the Leadtek 9101X GPS Module are as follow:
Items
Description
Length
15.0 ± 0.3 mm
Width
14.0 ± 0.3 mm
Height
2.80 ± 0.3 mm
Weight
1.8 g
