Leadtek LR9101X - Reference Design

© 2009 Leadtek Research Inc. All rights reserved. Page 7/19
Leadtek Confidential - Information is subject to change without prior notice.
LR9101X Specifications Sheet Rev. 1.3
2.8. Reference design
All ground pads attach directly to ground plane by way of via.
All components are reference only.
Recommendation for the external antenna: antennas over 16dB.
