LR9101X Specifications Sheet Rev. 1.3
2.5. Recommended GPS Antenna Specification
This LR9101X receiver is designed for use with passive antenna.
Parameter
Specification
Antenna Type
Right-hand circular polarized passive antenna
Frequency Range
1575.42 ± 1.023 MHz
2.6. Environmental Specification
Item
Description
Operating temperature rang
-30 deg. C to +85 deg. C
Storage temperature range
-55 deg. C to +100 deg. C
Humidity
up to 95% non-condensing or a wet
bulb temperature of +35 deg. C
Altitude
18,000 meters (60,000 feet) max.
Velocity
515 meters/second (1000 knots)
max.
Jerk
20 meters/second
3
, max.
Acceleration
4g, max.
2.7. ESD Specification
Air Discharge: 2 ; 4 ; 8KV ( direct )
Contact Discharge: 2 ; 4 KV ( direct / indirect )
