14
AUX1 calibration Calibrate the value in the display unit for the current
water meter setting. Hold in the arrow-up button to
step through the values faster.
AUX2 in Specify the AUX2 input’s function.
See description above for AUX1 in.
Disabled/
Water meter/
Home/
Away/
Warning/
Alarm
AUX2 active Specify if the input will be activated when it is high
or when it is low.
High/Low
The settings below are only visible when the AUX2 in input is configured as water meter.
AUX2 pulse unit See description above for the AUX1 pulse unit.
liter/puls,
puls/liter
AUX2 pulse size See description above for AUX1 pulse size.
1-1000 (10
AUX2 calibration See description above for AUX1 calibration.
Analog input Select pressure or temperature sensor here, if a 4-20
mA analogue sensor has been connected.
Disabled
Pressure sensor
Temp sensor
The settings below are only visible when the Analog input is configured as pressure or temp sensor.
Sensor min The sensor’s minimum measurement value.
Sensor max The sensor’s maximum measurement value.
Event high Specify if a warning or an alarm will appear when
”Threshold high” is exceeded.
Disabled
Warning
Alarm
Threshold high Specify the measurement value at which an alarm
will appear when the value is exceeded.
Event low Specify if a warning or an alarm will appear when
”Threshold low” is exceeded.
Disabled
Warning
Alarm
Threshold low Specify the measurement value at which an alarm
will appear when the value is not attained.
Hysteresis Specify here how far the value will drop below the
Threshold high or go above the Threshold low before
an active warning is acknowledged automatically.
Output handling
AUX out active Indicates whether the AUX output is open or closed
when activated. If disabled, output will not be
activated during activities.
Disabled/
Open /
Closed
AUX out when Indicates if output will be activated when the device
is in Home or Away mode. Alternatively, you can set
the connection to activate in case of a warning or an
alarm.
Home/
Away/
Warning/
Alarm
