MAIN MENU
The landing page shows the current mode, time, state of
alarm and quick test index. Pause mode calculates the time
that remains before the system returns to its previous mode.
When you turn the device on, the system shows quick test
indexes in brackets which means that the shown value has
not been established yet.
Tightness test status page shows the status, the duration of
the analysis period and the longest pulseless period of the
tightness test. The alarm activates after a 24-hour analysis
period. The longest pulseless period can be used as a
reference if you wish to adjust Tightness test limits.
Flow test status page shows the status and the flow time of
the flow test. After the flow indicator turns off, it shows the
flow time of the last registered flow
Quick test status page shows the status and the index value
of the quick test. The maximum index limit of the quick test
is shown in brackets
ACTIVITY MENU
The menu contains a list of past activities. Each activity or
alarm will be saved in the system with its date, time and
type (WARN or ALRM). Cleared activities have been marked
with (CLR). The data is saved even if the system loses power.
STATUS MENU
The mode menu includes sensor data, AUX inputs and valves as well as AUX outputs.
Indicates registered pulses after installation or after resto-
ring factory settings. Current valve position (OPEN/CLOSED)
.
AUX input mode. If the port is configured for water me-
tering, and a pulse water meter is connected, the current
meter reading in litres is displayed here.
AUX output mode (OPEN/CLOSED).
HOME HH:MM
OK 0.37
TIGHTN. TST OK
24h MAX=XX
FLOW TEST ALRM
00:33:29
QUICK TEST WARN
1.37 (1.00)
TIGHTN. TST
27/11 19:23 ALRM
SENSOR=19365
VALVE=OPEN
AUX1=LOW
AUX2=12345
AUX OUT=OPEN
To Next Page
